Advertising bender machine BWZ-A for channel letter /LED letter making

FOB Reference Price:Get Latest Price
$2,500.00 - $7,500.00 / Set | 1 Set/Sets channel letter bender (Min. Order)
Support Sea freight
Report Suspicious Activity
Quick Details
Place of Origin:
Hubei, China
Brand Name:
Model Number:
Machine Type:
Beading Machine
Raw Material:
Sheet / Plate Rolling
After-sales Service Provided:
Engineers service machinery overseas
letter bending thickness for al:
0.5-1.5 mm
Stainless steel bending thickness:
0.5 -1mm
Galvanize Plate bending thickness::
0.5 -1.0 mm
Carbon Steel bending thickness:
Max. processed width:
150mm letter auto bending machine
Apply material:
Aluminum strip bending, plastic, stainless steel strip bending, etc
360 degree rotary notching, 30-150 degrees angle
Supply Ability
Supply Ability:
1000 Set/Sets per Month letter bender
Packaging & Delivery
Packaging Details
according to export standard Woodedn case, Machine size 1740*760*1450 mm
Lead Time :
7 -10 wroking days

    Advertising  bender machine BWZ-A for channel letter /LED letter making

Brief Introduction:

Automatic CNC bending machine, (also called CNC letter bending machine or character bending machine)

is a new advertising production equipment, which can be used for logos, signs, neon signs, billboards, light

boxes production, outdoor advertising and other advertising production.


Applicable Industries: advertising industry, such as logos, signs, neon signs, billboards, light

boxesproduction, outdoor advertising and other advertising production.


diy led backlit channel letter sign Technical Data


Model            PEL-500                        PEL-600
Control Type

PC Control Type

(Price includes 1 set of Computer)

  Bending Material:   Aluminum, Single-fold-edge Aluminum, Double-fold-edge Aluminum

Aluminum, Stainless Steel, Carbon Steel, Mild Steel,

Galvanize Plate,Iron, Single-fold-edge Aluminum, Double-fold-edge Aluminum

  Aluminum Strip
  Single-Fold-Edge Aluminum
  Double-Fold-Edge Aluminum
  Stainless Steel   ×
  Carbon Steel   ×
  Mild Steel   ×
  Galvanized Plate   ×
  Iron Sheet   ×

Material Edge

Double-Folded-Edge (2 sides) &
Non Folded Edge Material (1 side)


Max. Processed Thickness:


  Aluminum Thickness: 0.45mm-2mm

Aluminum <2mm,Stainless steel <0.5mm,

Galvanize Plate <0.8mm


Max. Processed Width:






45-135 degrees


360 degree rotary notching, 30-150 degrees angle


Material feeding and bending




 Perfect Laser Bending Software



 AC 220V,50HZ (Special power, need to add transformer)



General Power


The Use Of Power








480 kgs


Import File Format

 Feed speed:

5 Meter / Min


0.05 mm


Remark: Price is including PC and PC screen.



diy led backlit channel letter sign Product Features:
1) Friendly man-machine interface, simple configuration. Simply enter the processing of text, graphic design files, and then the machine can process them on materials automatically.


2) Automatically feed, notch for two sides (angel 45-135), and roll Japanese linear module (screw drive), precision motor clamp.


3) No need of air pump, low voice and environment-friendly.


4) The operating system consist of stepping up, cutting, swing, promotion and demotion of, feed motor, bending motor, diffusion knife. Feeding ,bending and swinging are controlled by stepper motor. On the basis of the length , radian and angle which are figured out by microcomputer, the machine can feed , cut angle and bend precisely.

5) A unique 3-dimensional process simulation technology, two-dimensional design file to be able to display three-dimensional effects, supplemented by translation, rotation, zoom and other functions, enables full observation and monitoring of whole working process.


6) The original double-bent knife parallel bending technology to save time and greatly improve the processing efficiency, the maximum bending angle reached 150 °.

7) High precision machining, feeding precision can reach 0.01mm, bending accuracy up to 0.4°.


8) With precision automatic calibration function, based on the way of the processing material, self-adjusting process parameters, so that it can match with a variety of engraving machines and cutting machine, meet a variety of complex embedded process accuracy as much as possible.

9) Wide range of applications: PEL-600 CNC Bending machine can process 2mm strip of aluminum, 0.8mm galvanized steel, 0.5mm Stainless Steel and iron and other metal sheet.


10) It can work in 0.05 precision, and work together with laser engraving machine, plasma cutting machine to realize the advertisement processing.


Vidoe: Perfect Laser-Advertising Letter Laser Welding Machine :


diy led backlit channel letter bender details:
