Small Size Fiber Laser Cutting Machine For Metal Cutting

FOB Reference Price:Get Latest Price
$30,000.00 - $50,000.00 / Unit | 1 Unit/Units (Min. Order)
Model Number:
PE-F4040 PE-F6060 PE-F6040
Power(W):
300W 500W 700W 1000W
Lead Time:
Quantity(Units) 1 - 1 >1
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 1 Units)
Customized packaging (Min. Order: 1 Units)

More

Graphic customization (Min. Order: 1 Units) Less
Report Suspicious Activity
Overview
Quick Details
Applicable Material:
Metal, Stainless Steel
Laser Type:
Fiber Laser
Cutting Area:
400*400/600*400/600*600mm
Cutting Speed:
5-20 Meters/Min
Graphic Format Supported:
AI, PLT, DXF, BMP
Application:
Laser Cutting
Warranty:
3 years
After-sales Service Provided:
Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
Place of Origin:
Hubei, China
Brand Name:
Perfect Laser
Certification:
CE, ISO, FDA
Condition:
New
CNC or Not:
Yes
Control Software:
NC
Cooling Mode:
Water Cooling
Cutting Thickness:
500w: 1-5mm Carbon Steel
Product name:
Fiber Laser Cutting Machine
Model:
PE-F4040/6040/6060
Laser type:
Fiber laser Source
Laser power:
200w / 300w / 500w
cutting speed:
5-20 Meters/Min
Laser wavelength:
1070nm
Supporting format:
PLT,DXF,BMP,AI
Power demand:
380V / 50Hz
Cooling way:
Water cooling
Worktable max. loading:
1000kgs
Supply Ability
Supply Ability:
5000 Unit/Units per Year Fiber Laser Cutting Machine
Packaging & Delivery
Packaging Details
2350 x 1410 x 2100 mm
980 x 730 x 680 mm
2 Packages
Port
Shanghai Port, China
Lead Time :
Quantity(Units) 1 - 1 >1
Est. Time(days) 15 To be negotiated
Product Description

Small Size Fiber Laser Cutting Machine For Metal Cutting

(Model: PE-F4040 / 6040 / 6060)

Small size Fiber Laser Cutting Machine is suitable for small metal sheet cutting. There are 3 cutting formats for you to choose from, 400x400mm, 600x400mm and 600x600mm.
This kind of small size Fiber Laser Cutting Machine is not only save the space to customer, but also save the cost.
The appearance of the fiber laser cutter is very small and easy to move.
No consumable, maintenance-free and has long life are the most advantages of the Fiber Laser Cutting Machine.


Application
Applied materials: The small size fiber laser cutting machine is widely applied for cutting carbon steel, mild steel, stainless steel, silicon steel, aluminum alloy, titanium alloy, galvanized steel sheet, pickling board, and many kinds of metal materials.

Applied Industry: The small size fiber laser cutting machine is widely applied in sheet metal processing, aviation, spaceflight, electronics, electrical appliances, subway parts, automobile, machinery, precision components, ships, metallurgical equipment, elevator, household appliances, gifts and crafts, tool processing, adornment, advertising, metal foreign processing various manufacturing processing industries.
Product Features


1.Most excellent beam quality: It has the smaller focus of laser beam, high efficiency, high precision and best cutting quality.
2.High cutting speed: Cutting speed is 2
-3 times compare to the same power Co2 high power laser cutting machine.
3.Stable operation: Adopt the world's top imported fiber laser source, have stable performance, the core components can service up to 100,000 hours lifetime.
4.High photoelectric conversion efficiency : The photoelectric conversion efficiency of fiber laser cutting machine is 3 times compare to the high power co2 laser cutting machine.
5.Low cost: Save energy and protect the environment.Photoelectric
conversion rate is up to 25-30%. Low power consumption is about 20% to 30% of the traditional co2 laser cutting machine.
6.Less maintenance: Fiber optic cable transmission without mirrors, have good beam transmission rate, and saving maintenance cost.
7.Simple operation: Free of maintenance, no need to adjust the laser beam any more.


Detailed Images


1.Fiber Laser Source:Adopt world famous fiber laser source (IPG / Raycus / Max/ N-Light / Mopa), the cutting speed can up to 15M/min.
2.Laser Cutting Head:American Import fiber laser cutting head with dynamic autofocus function, can keep same distance according to  metal plate and cutting head during cutting.
3.Working Platform:There is a drawer under the working platform. After metal sheet cutting, the small pieces will fall down into the lower drawer for easy collecting.
4.Cutting Observation Window:The green glass cover window can filter the laser beam, no eye injury and no odor. Environmentally friendly and beautiful.
5.PC Control System:Humanized separate PC control system, PC screen can be rotated 180 degree.
6.Japan import Servo Motor & Driving System:Extreme precise positioning;Make moving positioning mechanism operate smoothly;Reliably and free of maintenance
7.Double Rack:Adopt double-drive rack transmission system, can ensure the cutting precision and fast speed.
8.Control System:Adopt NC Studio control system, have powerful edit function, can meet a wide range of cutting needs.

Technical Datas
Model
PE-F4040
PE-F6040
PE-F6060
XY working area
400x400mm
600x400mm
600x600mm
Laser type
Fiber laser Source
Laser power
200w / 300w / 500w
Max.cutting thickness (CS)
1-2mm(200w) / 1-3mm(300w) / 1-5mm(500w)
Table-driven system
Japanese imported Yaskawa / Panasonic
servo motor& driving system
Taiwan Hiwin/KH Precision Gear Track
Taiwan Hiwin/KH Precision Ball Track
Transmission method
Ball screw transmission
Laser technology
Germany technology
Max. cutting speed
5-20 Meters/Min (according to materials)
Max. location speed
60m/min
Laser wavelength
1070nm
Minimum line width
≤0.1mm
Location precision
≤±0.05mm
Re-location precision
±0.02mm
Max. Moving speed
100m/min
Supporting format
PLT,DXF,BMP,AI
Power demand
380V / 50Hz
Cooling way
Water cooling
Worktable max. loading
1000kgs
Focus method
Following and automatic adjust focus
Control method
Offline movement control
Control software
Perfect Laser professional laser cutting software
